Find a Peltier-based cuvette holder
Featured Product:
The Cyl 100 provides precise Peltier-based temperature control for a liquid sample in a 10-cm cylindrical cuvette. Magnetic stirring under each of the two stoppers maintains uniform temperature throughout the cell. Reach temperatures from well below 0 C to 110 C. Mount the Cyl 100 in your UV/Vis spectrophotometer or adapt it to your own experiment. This product is provided with a NIST-traceable calibration certificate.
Specifications:
| Number of cuvettes controlled | 1 | |
| Number of temperatures controlled | 1 | |
| Typical use | Absorbance with 100 mm path | |
| Standard cuvette size (outside) | 102.5 mm | |
| Beam ports per cuvette | 2 | |
| Entrance port diameter | 12 mm | |
| Factory set temperature range | -40 °C to +105 °C | |
| Temperature range easily achievable | -20 °C to +110 °C | |
| Temperature precision | ±0.01 °C | |
| Temperature accuracy full range | within ±0.30 | |
| Temperature reproducibility | Better than ±0.07 | |
| Thermistor probes accepted | ±0.2 °C from 0 ⁰C to +100 ⁰C | |
| Thermistor probes accepted | Series 400 or Series 500 | |
| Number of magnetic stirrers | 2 | |
| Magnetic stirring motor type | Stepper | |
| Magnetic stirring speed range | 1-2500 | |
| Default stirring speed | 1200 rpm |
