Brr 30/Eclipse
Temperature-controlled cuvette holder with extended low temperature response for the Agilent Cary Eclipse Fluorescence SpectrophotometerThe Brr 30/Eclipse is a temperature-controlled cuvette holder for use from +110 °C down to -55 °C. This model has been adapted for use in the Cary Eclipse Fluorescence Spectrophotometer. Remove the existing cell holder and lock the Brr 30/Eclipse down in its place, using the lever mounted in the front. Due to its flash lamp source, the Eclipse has “room light immunity,” permitting the utilities, wires and tubes, to exit the sample compartment without interfering with a measurement. Use the Brr 30/Eclipse to set and maintain precise sample temperatures and stir at a steady reproducible rate, while bathing the cuvette in a controlled gaseous environment. This product is provided with a windowed vest to enhance performance at low temperatures and minimize condensation that may form on the windows. Circulating water is used to remove heat from the Peltier heat exchanger. Control the Brr 30/Eclipse, using the TC 1B Temperature Controller included in the purchase price. For additional control and temperature monitoring, use Quantum Northwest’s computer control software, T-App, available for purchase.
Three optical ports
temperature control from -55°C to +110°C
Precise stepper-motor-driven magnetic stirring
Lid to improve temperature stability
Lifter to aid cuvette removal
Threaded inserts to mount windows or filters
Optical slit holders to control illuminated volume
Windowed vest included for use at very low temperatures
Dry gas purge for work at low temperature
Base and for mounting in spectrometer
Probe input for sample temperature
NIST-traceable temperature calibration
